Cadre : Spark Carbon HMF Mainframe with Alloy 6011 Swingarm, Integrated Suspension Technology, Flex Pivot / Adjustable head angle, Syncros Cable Integration System, BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fourche : RockShox Pike RL3 Air, Custom Charger 3-Mode Damper, 15x110mm Maxle Lite / 44mm offset / Tapered steerer, Lockout / Reb. Adj. / 130mm travel
Amortisseur arrière : RockShox Deluxe Select RL3 Trunnion, 3 modes / Lockout-Trail-Descend, Debon Air / Reb. Adj., Travel 120mm / T165X45mm
Levier de contrôle : SCOTT TwinLoc 2 Technology, Suspension & Dropper Remote, 3 Suspension modes
Dérailleur arrière : SRAM NX Eagle 12 Speed
Manettes de dérailleur : SRAM SX Eagle Trigger
Pédalier : SRAM X1 Eagle DUB, 55mm CL / 32T
Boitier de pédalier : SRAM DUB PF 92 MTB Wide / shell 41x92mm
Chaîne : SRAM CN NX Eagle
Cassette : SRAM SX-PG1210 / 11-50 T
Freins : Shimano MT501 Disc
Disque de frein : Shimano SM-RT54 CL / F&R 180mm
Cintre : Syncros Fraser 2.0 DC Alloy 6061 D.B., mini Rise / back sweep 8° / 760mm, Syncros Performance XC lock-on grips
Potence : Syncros DC 2.0, Syncros Cable Integration System, 0° rise / 6061 Alloy / 31.8mm / 1 1/8″
Tige de selle : Syncros Duncan Dropper Post 2.5, 31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
Selle : Syncros Tofino 2.5 Regular
Jeu de direction : Syncros – Acros Angle adjust & Cable Routing HS System, +-0.6° head angle adjustment, ZS56/28.6 – ZS56/40 MTB
Moyeu avant : Formula CL-811 / 15x110mm
Moyeau arrière : Formula CL-148S / 12x148mm, Syncros Axle w/Removable Lever with 6mm Allen, T30 and T25 Tools
Rayons : Stainless Black 15G / 1.8mm
Jante : Syncros X-30SE / 32H / 30mm, Tubeless ready
Pneu avant : Schwalbe Wicked Will 29×2.4″ EVO, Super Ground / TLE / 67EPI / Addix Speed Grip
Pneu arrière : Schwalbe Wicked Will 29×2.4″ EVO, Super Ground / TLE / 67EPI / Addix Speed Grip
Extras : Syncros Fork Fender
Poids en Kg (App.) : 13.5 (Tubeless setup)
Poids en Lbs (App.) : 29.76 (Tubeless setup)
Poids global : 128kg, Le poids total comprend le vélo, le pilote, l’équipement et les bagages supplémentaires.
